Product TVC Model Highlights Parameter details

DS800Rally

It combines the comfort of ADV models with the wildness of off-road models. The upgraded off-road capabilities enable it to adapt to more terrains. The ABS + TCS that can be turned off to offer more possibilities for showing off off-road skills.

Video

Features

Water cooling engine

KEL800 twin-cylinder water-cooled engine, free travel with power

Specially tuned ABS

The specially tuned ABS for unpaved roads can be turned off with one click

Adjustable shock absorption

With a shock absorber travel of 200mm at the front and 190mm at the rear, the KYB front and rear shock absorbers are adjustable

Larger fuel tank for long endurance

24L large-capacity rotomolded fuel tank.

high-quality off-road tire

21-inch front and 18-inch rear spoked wheels + Pirelli all-terrain tires.

Better riding comfort

Handlebar heating and seat heating functions

Parameter details

Overall size (L × W × H)2380x910x1460mm
Wheel base1576mm
Seat height850mm
Ground clearance220mm
Net weight213kg
Maximum speed190km/h
Front  tire  size90/90-21
Rear tire size150/70 R18
 Fuel tank volume L24L

Front suspensionKYB front up-side-down adjustable suspensions
Rear suspension KYB rear single suspension with multi-link (adjustable Preload & damping)
Front brakeNISSIN Fr. dual disk brake
Rear brakeNISSIN Rr. disk brake
ABSABS + TCS
wheelSpoke wheel
LightFull LED lights
Meter 7 inches TFT meter with TPM tire pressure meter
Engine typeDual cylinder, 8 valves, liquid-cooled，DOHC
Displacement (cc)798
Compression ratio12:01
Maximum power93.8hp(70kw)/9000rpm
Maximum torque81N.m/6500rpm
Starting methodElectric
Ignition systemEFI
Gearbox6-speed
